Description

PageTek 4 transmitters have either 5 or 10 zone inputs which can be configured for voltage or volt-free operation.

They can be programmed to send data or text messages direct to pagers. Each message can be free formed and each zone can support a different message for each state (active and passive).

Programmable functions allow for adjustable trigger delay times, repeats and interactive states between inputs. Programming is from a PC via USB with the optional programming kit.

The transmitters can be supplied as 12v, 24v or mains operated versions. The latter have integral power supplies which can be fitted with an optional battery back-up kit (A812E)

5-Zone
PT4-05-12V – 5 zone 12VDC programmable PageTek 4 transmitter with aerial. 1 watt RF output power
PT4-05-AC – 5 zone Mains powered programmable PageTek 4 transmitter with aerial. 1 watt RF output power

10-Zone
PT4-10-12V – 10 zone 12VDC programmable PageTek 4 transmitter with aerial. 1 watt RF output power
PT4-10-AC- 10 zone Mains powered programmable PageTek 4 transmitter with aerial. 1 watt RF output power
